SENSE IP65
SENSE IP65 595x595 White 5160lm 4000K Ra>90 DALI-2 / Push Dim
Article code:
8246096100
EAN:
5703821181204
Download
Electrical
System wattage:
43W
Voltage:
220-240V
Frequency (Hz):
50/60Hz
Max. luminaires per circuit breaker:
B10: 12, B16: 20, C10: 21, C16: 34
Leakage current (mA):
0.29
Light technic
Type of light source:
LED
Luminous flux:
5160lm
Efficacy:
120 lm/W
Colour temperature:
4000K
Colour rendering (CRI):
Ra>90
MacAdams factor:
SDCM: 3
Lifetime:
L80/B50>100,000
Lifetime:
L90/B10>50,000
Light distribution:
Direct
Optic:
Prism Optic
UGR:
UGR<19
Visible flicker (PstLM):
0,07
Stroboscopic flicker (SVM):
0,01
Control/Dimming
Type:
DALI-2 / Push Dim
Protection
Luminaire class:
Class I
IK Class:
IK07
IP Class:
IP54/IP65
Energy and approvals
Contains light source of energy class:
D
Breeam:
Fulfils Hea 01 for flicker free lighting
Materials and finish
Housing:
Sheet steel
Colour:
White smooth (Ral 9016 gloss 30)
Optics:
Tempered glass
Mounting/Connection
Mounting:
Recessed, Indoor
Module:
595x595 Exposed T-carrier 15/24mm
Cable:
Cable 5x0,75mm² 2,5m Halogen free
Dimensions
Length (mm) L:
595
Width (mm) W:
595
Height (mm) H:
94
Weight (kg) gross/net:
12.7 / 12.1
Packaging
Packing dimensions (mm):
625 x 605 x 97
